Vehicle lift CARRICO

Cost-efficient transport between floors

The vehicle lift CARRICO is an interesting alternative to the TRAFFICO when lower lifting heights and less frequent use are needed.

The CARRICO has been type-tested in accordance with the EU Machinery Directive 2006/42/EC. The conveying speed is limited to 0.15 m/s. Furthermore, this car lift is delivered with automatic sliding doors and cabin equipment designed for the transport of vehicles and passengers.

Advantages

Saves installation space, as no ramp is required
Especially suitable for narrow shafts
Cost-effective way to transport cars
Automatic travel for lifts with 2 stops for maximum comfort
Low noise

Technical Data CARRICO

Lifting height	max. 25 m
Nominal speed	0.15 m/s
Pit depth	850 mm (standard) - Reduction possible
Nominal load	max. 4,200 kg
Cabin width	2,500 - 3,000 mm
Cabin depth	5,500 - 7,000 mm
Cabin height	2,100 - 3,000 mm
Stops	2 - 8
Accesses	2 - 16 (one above the other or opposite)

Shaft head height	min. 2,700 mm - depending on headroom
Shaft width	Cabin width + 800 mm
Shaft depth	Cabin depth + 800 mm
Axle load	max. 1,750 kg - forklift operation prohibited
Control	Pushbutton control in microprocessor technology with extensive control functions
Drive	Hydraulic power unit with pump-motor suboil unit
Operating modes	Fully automatic travel (2 stops) Automatic travel (from 3 stops)
Directives	Machinery Directive 2006/42/EC DIN EN 81-41:2011
Passenger ride	Car with passenger escort allowed

Download Planning Material

TRAFFICO, CARRICO - car lifts, Planning guide

Lödige (United Kingdom) Ltd., (Status: 2020-01-24) — pdf

Download Lödige (United Kingdom) Ltd., (Status: 2020-01-24) TRAFFICO, CARRICO - car lifts, Planning guide

CARRICO, Planning Bundle (#1) EN

Cabin size: 2700 x 5500 x 2100 mm Tender specification, sample drawings (pdf & dwg) — rar

Download Cabin size: 2700 x 5500 x 2100 mm Tender specification, sample drawings (pdf & dwg) CARRICO, Planning Bundle (#1) EN

CARRICO, Planning Bundle (#2) EN

Cabin size: 2800 x 5800 x 2100 mm Tender specification, sample drawings (pdf & dwg) — rar

Download Cabin size: 2800 x 5800 x 2100 mm Tender specification, sample drawings (pdf & dwg) CARRICO, Planning Bundle (#2) EN

Possible applications of CARRICO:

Single-family detached home
Multi-family buildings, office buildings, hotels

Single-family detached home

With the CARRICO, cars can be parked in the basement without building a long drive-in ramps. It is a perfect solution to create more parking space in a single-family detached home.

Multi-family buildings, office buildings, hotels

With the CARRICO you can create additional parking space in multi-family houses, office buildings and hotels. It is particularly suitable for the development of up to 20 parking spaces in basements.
